450 kw AC Electric Motor
600 hp, 6 pole, 6600 volt < Back
| Type | AC |
| Make | Toshiba |
| Model Number | TIK FCKNW D450LL |
| Year Of Manufacture | 2014 |
| KW | 450 |
| HP | 600 |
| Poles | 6 |
| Rated RPM | 980 |
| Rated Frequency | 50 |
| Rated Voltage | 6600 |
| F/L Amps | 49 |
| Protection Rating | IP 56 |
| Mount | B3 Foot |
| Frame | 450LL |
| Weight | 4,700 kg |
| Total Length | 2495 mm |
| Total width | 2050 mm |
| Total height | 1168 mm |
| Centre shaft height | 450 mm |
| Feet Measurements | 1120 mm front to back, 750 mm across |
| Front hole to end of shaft | 525 mm |
| Shaft diameter | 120 mm |
| Shaft length | 210 mm |
| Quantity | 1 |
| Condition | New |
